Film Capacitor
| Specification Reference Standard | GB/T 14579(IEC 60384-17) |
| Type | MPP(CBB21)、PPS(CBB81)、MMKP82 |
| Rated Voltage | 100V、250V、400V、630V、1000V、2000V |
| Capacitance Range | 0.001μF~3.3μF |
| Capacitance Tolerance | ±5%(J),±10%(K) |
| Voltage Proof | 1.5UR5sec |
| Insulation Resistance(IR) | Cns0.33uF,IR≥15000MQ;Cn>0.33uF,RCn>5000s at100V,20℃,1min |
| Dissipation Factor | For60sec/25℃For 60sec/25℃ |
| Climatic Category | 0.1%Max,at 1KHz and 20℃ |
| Operation Temperature Range | 40/105/21-40℃~105℃(+85℃~+105℃:decreasing factor1.25%per’℃ for UR) |
| Specification Reference Standard | GB/T 7332(IEC 60384-2) |
| Type | MEF(CL21)、MEM(CL21X)、MEMB(CL21X-B)、MET(CL20) |
| Rated Voltage | 63V、100V、250V、400V、630V、 |
| Capacitance Range | 0.001μF~10μF |
| Capacitance Tolerance | ±5%(J)±10%(K) |
| Voltage Proof | 1.5UR,5sec |
| Insulation Resistance(IR) | Cn≤0.33uF,R≥15000M2:Cn>0.33uF,RCn>5000s at 100V,20℃,1min |
| Dissipation Factor | 1%Max,at 1KHz and 20℃ |
| Climatic Category | 55/105/21 |
| Operation Temperature Range | 55℃~105℃(+85℃~+105℃:decreasing factor1.25%per℃ for UR) |
Fully automated production line
Running 24 hours a day
Good quality
Short lead time
Professional engineering and service team
Assit in model selection
Best service
24hours online
SUFFICIENT STOCK
Fast delivery
Application Area :
LED Light
washing machine
charger
